Specifications (MB441/MB451/MB451w)
-184-
Specifications (MB441/MB451/MB451w)
General Specifications
MFP Model Model Number
MB441 N22205B
MB451 N22206B
MB451w N22207B
MB441 MB451 MB451w
CPU Printer controller
PowerPC405 , 330 MHz
Scanner controller
ARM9 max 266 MHz
Memory Resident Printer controller
256 MB
Scanner controller
128 MB
Flash
ROM
Printer
Controller
SPI ROM : 16MB x 2
Scanner
Controller
NAND : 64 MB
SPI : 2 MB
Storage Device -
Weight 20 kg (including consumables)
Dimensions 427 (W) x 425 (D) x 455 (H)
Power supply N22205A, N22206A, N22207A, N22208A: 120VAC ±10% , 50/60Hz ±2%
N22205B, N22206B, N22207B, N22208B: 220V AC ±10%, 50/60Hz ±2%
Power consumption Typical operation
540 W
Idle
80 W
Peak
950 W
Sleep mode
Less than 3 W
Power save mode
Less than 14 W
Off mode
Less than 0.5 W
Typical operation
580 W
Idle
80 W
Peak
950 W
Sleep mode
Less than 3 W
Power save mode
Less than 14 W
Off mode
Less than 0.5 W
Typical operation
580 W
Idle
80 W
Peak
950 W
Sleep mode
Less than 3 W
Power save mode
18 W
Off mode
Less than 0.5 W
Operating condition Operating
Temperature : 10 to 32°C, humidity : 20 to 80% RH
Idle
Temperature : 0 to 43°C, humidity : 10 to 90% RH
Interface USB 2.0 (Hi-Speed), Ethernet 10BASE-T/100BASE-TX USB 2.0 (Hi-Speed), Ether-
net 10BASE-T/100BASE-TX,
IEEE820.11 b/g/n Wireless
LAN
Display Graphics panel 84.1(W) x 33.6(H) mm, 320 x 128 dots
Supported OS Windows 7, Windows Vista, Windows Server 2008 R2, Windows Server 2008, Windows
XP, Windows Server 2003
Mac OS X 10.4.0-10.7
Please refer to "Product Requirements" (P.46)
