Connecting to a Computer

-63-

Setup

8 Select the name of your machine whose

[Connection] is [USB], and then check

that [OKI MB491(PS)] or [OKI

MB491(PCL)] is displayed in [Print

Using].

9 Click [Add].

10 Check that the name of your machine is

displayed in [Printer List], and then

close the window.

11 Remove "Software DVD-ROM" from the

computer.

The installation is complete.
