Configuring the Network Settings
-71-
Setup
1
12 Click [If you understand the security
risks but want to share files without
running the wizard, click here.].
If the screen below appears, select [Share this
folder] and click [Permissions]. Proceed to step
15.
13 Select [Just enable file sharing] in
Windows Firewall, and then click [OK].
14 Select the [Share this folder on the
network] and [Allow network users
to change my files] check box, and
then click [OK].
Proceed to "Creating a Profile for Scan To Network
PC" P. 75
15 Click [Add].
16 Enter the value in C-2 in the entry field
and click [OK].
17 Select the [Allow] check box for [Full
Control], and then click [OK].
Proceed to "Creating a Profile for Scan To Network
PC" P. 75
