EN
1
12
USE
Control panel
Button Function Display
A Door Closed: Press and hold for approximately 2 Seconds to open the door and
turn the motor on at the last speed set.
Door Open: Press briefly to turn the motor Off or On.
Displays the set speed.
B Decreases the working speed. The number of lighted segments decreases.
C Increases the working speed. The number of lighted segments increases.
D Activates/Deactivates Intensive speed. This speed is timed to run for 10
minutes. At the end of this time the system will automatically return to the speed
set before. Suitable to deal with maximum levels of cooking fumes. Cannot be
activated when in 24H mode.
The indicator I flashes and all the segments on
the Display are lit.
Press and hold the button for approximately 5 seconds, with all the loads turned
off (Motor and Lights) and no alarms in progress, to turn the Activated
Charcoal Filter Alarm On / Off.
Button "C " flashes twice – Alarm On.
Button "C " flashes once – Alarm Off.
E Activates/Deactivates 24H speed. This starts the motor at a speed that allows
suction of 100 m3/h for 10 minutes every hour. This mode cannot be activated
if Intensive or Delay modes are active.
Displays 24 and the segments on the Display
light up in cycle.
Press and hold the button for approximately 5 seconds, with all the loads turned
off (Motor and Lights) and no alarms triggered, to turn the Remote control On
/ Off.
(Motor LED bar flashes twice) - Remote control
On.
(Motor LED bar flashes once) - Remote control
Off.
F Activate / Deactivate Delay. Can be activated with motor on (except for
Intensive and 24H mode). Activates automatic shutdown of the Motor and the
Lighting with a 30’ delay.
Displays a Clock symbol.
Press and hold for 5 Seconds to Activate / Deactivate Lock Keyboard mode
for example in order to clean the Glass.
The Leds light up and run a start-up sequence.
G Performs a Reset of the Filter saturation alarm when the button is pressed for
approximately 3 seconds when all the users (motor + lights) are turned off
After 100 hours in operation the Drop symbol is
displayed to indicate saturation of the Metal
Grease Filters.
After 200 hours in operation the letter C is
displayed to indicate saturation of the Activated
Charcoal filters.
H Modifies the intensity of the Lighting each time the Button is pressed, in cycle. -
I Door Closed: When pressed and held for approximately 2 seconds opens the
door half way and turns the lighting on to maximum intensity. The intensity can
be modified using button H.
- When the button is pressed again, the lighting turns off and the door closes.
- When button A is pressed, the Lights turn off and the motor only works at the
first two speeds.
Door Open: Press briefly to turn the lighting On or Off.
-
L Door Closed: Press and hold for approximately 2 Seconds to open the door,
turn the motor on at speed three and turn the lighting on at maximum intensity.
Door Open: When pressed and held for approximately 2 seconds turns off the
motor and the lighting, cancelling any function that may be active and closing
the door.
-
Warning:
During the Opening and Closing phase the panel has a guard device that reverses the direction of movement in the event of blockage during
the movement itself. It performs a maximum of 6 attempts before the “
“ icon flashes to indicate actual blockage. At this point, remove
the obstacle preventing movement if possible, then press and hold button L for 2 seconds. The panel will once again make a maximum of 6
attempts to close or open before reverting to blocked status if movement is not successful. In this case it will be necessary to call the Technical
Service Department.
B
A
D
C
E
G
F
I
H
L
