Optoma WU1500 [10/77] Introduction
![Optoma WU1500 [10/77] Introduction](/views2/1304293/page10/bga.png)
English
10
INTRODUCTION
Connections
9
11
16
1 2 3 6
10
7 854
12131415
No Item No Item
1. 3D Sync OUT Connector 9. HDBaseT Connector
2. DVI-D Connector 10. RJ-45 Connector
3. VGA IN / YPbPr Connector 11. SERVICE Connector
4. VGA OUT Connector 12. USB Power Out (5V 0.5A) Connector
5. HDMI Connector 13. 3G-SDI IN Connector
6. Component/RGBHV IN Connector 14. Video IN Connector
7. Remote OUT Connector 15. RS-232C Connector
8. Remote IN Connector 16. Power Socket
