English
23
USING THE PROJECTOR
Menu navigation and features
The projector has multilingual on-screen display menus that allow you to make image adjustments and change a
variety of settings. The projector will automatically detect the source.
1. To open the OSD menu, press "Menu" on the remote control or the projector keypad.
2. When OSD is displayed, use pqtu to navigate within the menu and adjust a setting up or down.
3. Press "Enter" to enter the submenu or conrm the selection/setting.
4. Press "Exit" to return to the previous menu or exit menus if at top level.
Display Mode
Brightness
Contrast
Sharpness
Color
Tint
Phase
Frequency
Horz Position
Vert Position
OUTPUT
SETUP
OPTION
Presentation
50
50
2
50
50
50
50
50
50
Settings
Sub Menu
Main Menu
