INTRODUCTION
Product Overview
4
5
2 3
1
5 56
7
8
9
4
10
13
12
11
Note: Do not block projector inlet or outlet air vents.
(*) optional accessory varies depending on model, specication, and region.
No Item No Item
1. Lens 8. Kensington
TM
Lock Port
2.
Lens Release Button
9.
Power Switch
3. Front IR Receiver 10. Power Socket
4. Tilt-Adjustment Feet 11. Ventilation (outlet)
5. Ventilation (inlet) 12. LED Status Indicators
6. Input / Output 13. Top IR Receiver
7. Keypad
