English
11
INTRODUCTION
Keypad
1 2 6 7
8
10
3 54
9
11
No Item No Item
1.
Power
7.
Lens
2.
Shutter
8.
Zoom
3.
Auto
9.
Exit
4.
Enter
10.
Four Directional Select Keys
5.
Input
11.
Menu
6.
Focus
