English
61
ADDITIONAL INFORMATION
Signal
Type
Resolution
Frame
rate (Hz)
QD881 VGA
BNC
HDMI DVI 3G-SDI
HDBaseT
CVBS
HDTV
720p 60 V V V V — V —
1080p 23 V V V V — V —
1080p 24 V V V V — V —
1080p 25 V V V V — V —
1080p 29 V V V V — V —
1080p 30 V V V V — V —
1080p 50 V V V V — V —
1080p 59 V V V V — V —
1080p 60 V V V V — V —
Mandatory
3D
Frame Packing
1080p
24 — — V — — V —
Frame Packing
720p
50 — — V — — V —
Frame Packing
720p
60 — — V — — V —
Side by Side
1080i
50 — — V — — V —
Side by Side
1080i
60 — — V — — V —
Top and Bottom
720p
50 — — V — — V —
Top and Bottom
720p
60 — — V — — V —
Top and Bottom
1080p
24 — — V — — V —
Frame
sequential
3D
800x600 120 — — V — — V —
1024x768 120 — — V — — V —
1280x720 120 — — V — — V —
SD-SDI
480i YcbCr422
10bit
59.94 — — — — V — —
576i YcbCr422
10bit
50 — — — — V — —
HD-SDI
720p YcbCr422
10bit
50 — — — — V — —
59.94 — — — — V — —
60 — — — — V — —
1080i YcbCr422
10bit
50 — — — — V — —
59.94 — — — — V — —
60 — — — — V — —
1080p
YcbCr422 10bit
23.98 — — — — V — —
24 — — — — V — —
25 — — — — V — —
29.97 — — — — V — —
30 — — — — V — —
1080sF
YcbCr422 10bit
25 — — — — V — —
29.97 — — — — V — —
30 — — — — V — —
