USING THE PROJECTOR
PICTURE menu
Display Mode
Brightness
Contrast
Sharpness
Color
Tint
Phase
Frequency
Horz Position
Vert Position
OUTPUT
SETUP
OPTION
Presentation
50
50
2
50
50
50
50
50
50
PICTURE (1/2)
Auto Image
3D Display
Color Matching
Advanced
OUTPUT
SETUP
OPTION
PICTURE (2/2)
Display Mode
There are many factory presets optimized for various types of images.
Presentation: This mode is suitable for showing PowerPoint presentations when the projector is
connected to the PC.
Video: This mode is suitable for watching video.
Bright: Maximum brightness from PC input.
DICOM SIM: This mode can project a monochrome medical image such as an X ray radiography, MRI,
etc.
2D High Speed: Display the status of 2D High Speed mode.
Note: If the resolution of the input source is 800x600 at 120Hz, 1024x768 at 120Hz, or 1280x720
120Hz, then the display mode will automatically switch to 2D High Speed.
3D: Recommended setting for 3D mode enabled. Any further adjustments by the user in 3D will be
saved in this mode for further use.
User: Memorize user’s settings.
Save to User: Save the display mode settings in user prole.
