3-2
Confidential
2. PACKING
Quick setup guide
Option carton
AC cord bag ASSY
Pad ASSY
Pad ASSY
Pad ASSY
Protective material
ASSY
Machine
LT
Styrofoam pad R
Styrofoam pad F
Paper tray pad ASSY (SP)
Carton
LT-5400
Carton pad 1
Carton pad 2
Carton
Carton spacer
Carton
spacer
Carton
outer
