Supermicro SYS-5019S-MN4 [10/61] Chapter 2 server installation

SuperServer 5019S-MN4 User's Manual Chapter 2: Server Installation

1817

Chapter 2

Server Installation

2.1 Overview

This chapter provides advice and instructions for mounting your system in a server rack.

If your system is not already fully integrated with processors, system memory etc., refer to

Chapter 4 for details on installing those specic components.

Caution: Electrostatic Discharge (ESD) can damage electronic components. To prevent such

damage to PCBs (printed circuit boards), it is important to use a grounded wrist strap, handle

all PCBs by their edges and keep them in anti-static bags when not in use.

2.2 Preparing for Setup

The box in which the system was shipped should include the rackmount hardware needed to

install it into the rack. Please read this section in its entirety before you begin the installation.

Choosing a Setup Location

• The system should be situated in a clean, dust-free area that is well ventilated. Avoid areas

where heat, electrical noise and electromagnetic elds are generated.

• Leave enough clearance in front of the rack so that you can open the front door completely

(~25 inches) and approximately 30 inches of clearance in the back of the rack to allow

sufcient space for airow and access when servicing.

• This product should be installed only in a Restricted Access Location (dedicated equipment

rooms, service closets, etc.).

• This product is not suitable for use with visual display workplace devices acccording to §2

of the the German Ordinance for Work with Visual Display Units.

Rack Precautions

• Ensure that the leveling jacks on the bottom of the rack are extended to the oor so that

the full weight of the rack rests on them.

• In single rack installations, stabilizers should be attached to the rack. In multiple rack in-

stallations, the racks should be coupled together.

• Always make sure the rack is stable before extending a server or other component from

the rack.

• You should extend only one server or component at a time - extending two or more simul-

taneously may cause the rack to become unstable.

Server Precautions

• Review the electrical and general safety precautions in Appendix B.

• Determine the placement of each component in the rack before you install the rails.

• Install the heaviest server components at the bottom of the rack rst and then work your

way up.

• Use a regulating uninterruptible power supply (UPS) to protect the server from power

surges and voltage spikes and to keep your system operating in case of a power failure.

• Allow any drives and power supply modules to cool before touching them.

• When not servicing, always keep the front door of the rack and all covers/panels on the

servers closed to maintain proper cooling.

Rack Mounting Considerations

Ambient Operating Temperature

If installed in a closed or multi-unit rack assembly, the ambient operating temperature of

the rack environment may be greater than the room's ambient temperature. Therefore,

consideration should be given to installing the equipment in an environment compatible with

the manufacturer’s maximum rated ambient temperature (TMRA).

Airow

Equipment should be mounted into a rack so that the amount of airow required for safe

operation is not compromised.

Mechanical Loading

Equipment should be mounted into a rack so that a hazardous condition does not arise due

to uneven mechanical loading.
