SuperServer 5019S-MN4 User's Manual Chapter 1: Introduction
Quick Reference Table
Jumper Description Default Setting
J7 LAN4 LINK ACK Off (Disabled)
J8 LAN3 LINK ACK Off (Disabled)
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 Clear CMOS See Chapter 4
JI
2
C1/JI
2
C2 SMB to PCI Slots Pins 2-3 (Disabled)
JPB1 BMC Enable/Disable Pins 1-2 (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1-JPL4 LAN1-LAN4 Enable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Enable Pins 1-2 (Reset)
LED Description Status
LE1 Rear UID LED Blue: On; Unit identied
LE3 PCI-E 3.0 M.2 LED Green: Blinking; Active
LEDBMC BMC Heartbeat LED Green: Blinking; BMC normal
LEDPWR Onboard Power LED Green: Solid on; Power on
Connector Description
BT1 Onboard Battery
COM1/COM2 COM1/COM2 Port Headers
Fan1-Fan4, FanA System/CPU Fan Headers
I-SATA0-I-SATA7 SATA 3.0 Connectors via Intel PCH (6Gb/s)
I-SGPIO 1/2 Serial_Link General Purpose I/O Connection Headers 1/2
IPMI_LAN Dedicated IPMI Gigabit (RJ45) Port
J23 M.2 Socket
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion Header
JOH1 Overheat LED Indicator
JPI
2
C1 Power I
2
C System Management Bus (Power SMB) Header
JPWR1 24-pin ATX Main Power Connector (Required)
JPWR2 +12V 8-pin CPU power Connector (Required)
JSD1/JSD2 SATA Disk On Module (DOM) Power Connectors
JSTBY1 Wake-On-LAN Enable Header
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID (Unit Identication) Switch
LAN1-LAN4 Gigabit (RJ45) LAN Ports
Connector Description
PCI-E (PCH) Slot 4 PCI-Express 3.0 x4in x8 Slot
PCI-E (CPU) Slot 5 PCI-Express 3.0 x8 Slot
PCI-E (CPU) Slot 6 PCI-Express 3.0 x8 in x16 Slot
SP1 Internal Speaker/Buzzer
USB 0/1 Back Panel USB 2.0 Ports
USB 2/3, USB 4/5 Front Accessible USB 2.0 Headers
USB 6/7 Back Panel USB 3.0 Ports
USB 8/9 Front Accessible USB 3.0 Header
USB 10 USB 3.0 Type-A Header
VGA Back Panel VGA Port
