1-2
SUPERWORKSTATION 7047GR-TPRF User's Manual
1-2 Serverboard Features
At the heart of the SuperWorkstation 7047GR-TPRF lies the X9DRG-QF, a dual
processor serverboard based on the Intel C602 chipset. Below are the main features
of the X9DRG-QF. (See Figure 1-1 for a block diagram of the chipset).
Processors
The X9DRG-QF supports two Intel
®
E5-2600 (v2) Series processors in LGA 2011
sockets (Socket R). Please refer to the serverboard description pages on our web
site for a complete listing of supported processors (www.supermicro.com).
Note: For Intel E5-2600(v2) processor support, BIOS version 3.0 or above is
required.
Memory
The X9DRG-QF has sixteen DIMM slots that can support up to 1 TB ECC
LRDIMM, 512 GB ECC RDIMM or 128 GB ECC/non-ECC UDIMM DDR3-
1866/1600/1333/1066/800 memory. Modules of the same size and speed are
recommended. See Chapter 5 for details.
SATA
A SATA controller is integrated into the chipset to provide a ten-port SATA
subsystem, which is RAID 0, 1, 5 and 10 supported. The I-SATA 0-1 ports are SATA
3.0 ports while the I-SATA2-5 and the S-SATA0-3 ports are SATA 2.0 ports. The
SATA drives are hot-swappable units.
Note: The operating system you use must have RAID support to enable the hot-
swap capability and RAID function of the Serial ATA drives.
PCI Expansion Slots
The X9DRG-QF has four PCI-E 3.0 x16, two PCI-E 3.0 x8 (in x16) and one PCI-E
2.0 x4 (in x8) slots for a total of seven PCI expansion slots.
Rear I/O Ports
The color-coded I/O ports include one COM port, a VGA (monitor) port, four USB
2.0 ports, a dedicated IPMI LAN port and two Gb Ethernet LAN ports.
IPMI
IPMI (Intelligent Platform Management Interface) is a hardware-level interface
specication that provides remote access, monitoring and administration for
