7-24

SUPERWORKSTATION 7047GR-TPRF User's Manual

iSCSI Conguration: This item displays iSCSI conguration information:

iSCSI Initiator Name

This item displays the name of the iSCSI Initiator, which is a unique name used

in the world. The name must use IQN format. The following actions can also

be performed:

•Add an Attempt

•Delete Attempts

•Commit Changes and Exit

•Discard Changes and Exit

•Change Attempt Order

•Commit Changes and Exit

•Discard Changes and Exit

Intel® I350 Gigabit Network Connections: These items display the following

information on the Intel I350 LAN connections.

NIC Conguration

Link Speed

Use this feature to change the link speed and duplex for the current port. The op-

tions are AutoNeg, 10Mbps Half, 10Mbps Full, 100Mbps Half, and 100Mbps full.

Wake on LAN

Select enabled to wake the system with a magic packet. The options are Enabled

and Disabled.

Blink LEDs

This feature allows the user to specify the duration for LEDs to blink. The range is

from 0 ~ 15 seconds. The default setting is 0.

PORT CONFIGURATION INFORMATION

This section displays the following port information:

•UEFI Driver

•Adapter PBA
