Karmel Baby Model No. 2626, 2626EX

Page 14

gmpopcorn.com

Unit Exterior – Parts List

Item

Part Description Qty.

Part Number

2626

2626EX

1

PLASTIC HANDLE 3/8

-

16 TAP

1

76075

7607

5

2

LID ASSEMBLY (includes handle)

1

16810

16810

3

KETTLE SUBASSEMBLY

(see Kettle Assembly

Breakdown section for itemized parts list)

1 111026 111026EX

4

CONNECTOR 90 DEGREE (see Kettle Lead

-

In

Parts Breakdown section for Kettle Lead Wire

Assembly)

1 46241 46241

5

1/2 CONDUIT BUSHING NM

1

82135NM

82135NM

6

WASHER 1/4 INTERNAL TOOTH

4

12383

12383

7

1/4

-

20 X 1/2 HX

HD SCREW

4

12382

12382

8

PLASTIC DUMP HANDLE

1

41139

41139

9

HANDLE WELDMENT

1

88732

88732

10

1/4

-

20 X 1/2 P/H PHIL

2

12471

12471

11

1/4

-

20 ACORN NUT

2

42229

42229

12

MOTOR ENCLOSURE

1

88740

88740

13

MOTOR COVER END PLATE

1

88739

88739

14

SCREW #8

-

32X3/8 PAN HD PH

4

74141

74141

15

STRAIN RELIEF #SR

-

10

-

2

1

87163

87163

16

MOTOR LEAD IN CORD ASSEMBLY

1

111034

111034

17

CABLE CLAMP

1

87219

87219

18

KETTLE DRIVE MOTOR 120V

1

88744

KETTLE DRIVE MOTOR

23

0V

1

88744EX

19

RUBBER

BUMPER

2

87247

87247

20

FACE PLATE

1

16925

16925

21

8

-

32 X 1/2 PH PAN T/S (Front Plate Screws)

8

87245

87245

22

FRONT DECAL 2626

1

88721

88721

23

1

-

3/8" BALL KNOB

1

111033

111033

24

STOP HANDLE

1

111005

111005

25

CONNECTOR CONDUIT FLEX

(straight 3/8 with screws)

1 47373 47373

26

1/2” CONDUIT BUSHING

1

82135NM

82135NM

27

STRAIN RELIEF SR7W

-

2

1

67060

67060

28

LEAD

-

IN CORD 15 AMP PLUG

1

87085

POWER SUPPLY CORD, EXPORT

1

42369

29

FLEXIBLE CONDUIT

1

82107

-

19

87107

-

19

30

SUPPORT BRACKET

1

111012

111012

31

HI CROWN ACORN

-

ZINC

3

77610

77610

32

5/16

-

1

8 X 1 HEX C/S 18

-

8 (Cap Screw)

1

12489

12489

33

PLAIN WASHER, STAINLESS

2

77865

77865

34

NYLON ROD END

1

111032

111032

35

5/16

-

18 X 1/2 PH TR M/S

2

12183

12183

36

SPACER .438ODx.323IDx.180

2

88741

88741

37

MOTOR MOUNT

1

111004

111004
