Gold Medal Karmel Baby [3/21] Installation instructions
![Gold Medal Karmel Baby [3/21] Installation instructions](/views2/1321716/page3/bg3.png)
Karmel Baby Model No. 2626, 2626EX
Page 3
gmpopcorn.com
INSTALLATION INSTRUCTIONS
Inspection of Shipment
After unpacking, check thoroughly for any damage which may have occurred in transit. Claims
should be filed immediately with the transportation company. The warranty does not cover
damage that occurs in transit, or damage caused by abuse, or consequential damage due to the
operation of this machine, since it is beyond our control.
Setup
1. Remove all packaging and tape before starting operation.
2. Prior to operation, rotate the top paddle into the mixing position and fix into place with
the wing bolt provided (see illustration below).
Paddles in Correct
Mixing Position
Wing Bolts
