6.7 ADJUSTING THE AUTOSTEAM

NOZZLE

(If Fitted)

To increase/reduce the amount of air injected into the

milk from the TurboCream nozzle (and therefore to

increase/reduce the amount of foam in the heated milk)

proceed as illustrated in

Fig. 18:

① Loosen the stainless steel tube (1) as illustrated in

Fig. 18.A.

② To increase/reduce the amount of air, tighten (turn-

ing clockwise) or loosen (turning anticlockwise) the

Teflon tube (2) as illustrated in Fig. 18.B.

③ Tighten the stainless steel tube again.

④ As far as concerns temperature settings, see the

relevant programming section.

NOTE

By reducing or increasing the length (tightening or

loosening) the tube/Teflon tube by a few fractions of a

mm/mm, there is a significant difference in the amount

of foam in the heated milk.

Fig. 18

Fig. 18.A

Fig. 18.B
