TRANSPORT AND HANDLING
MACHINE’S IDENTIFICATION
For any communication with the manufacturer
Victoria Arduino, always have the plate
number of the machine to hand.
The machine is carried in a pallet further more
machinery is inside cardboard boxes connected
to the pallet by frameworks.
Before starting any operation of transport and
movement, the operator has to:
•
Wear safety gloves, shoes and an overall with
elastic bands at the ends. The pallet transport
has to be made by suitable lifting means (like a
forklift truck).
m
ATTENTION DANGER OF COLLISION OR CRUSHING
During the handling the operator must pay
attention that in the operating area there
aren't any people, things or other objects.
Lift the pallet slowly at about a height of 30
cm. from the ground and then reach the
loading area. Proceed to the loading only after
having checked that there aren't any obstacles,
things or people in the way.
Once arrived at destination, always using a
suitable lifting means (e.g. forklift truck) make
sure that there aren't any things or people in
the download area, then bring the pallet to the
ground and handle it to reach 30 cm. from the
ground until the stocking and warehouse area.
m
ATTENTION DANGER OF COLLISION OR CRUSHING
Before the following operation, please check
that the load is in the correct position and that
it won't fall when cutting the frameworks.
The operator with gloves and safety shoes
must cut the frameworks and then stock the
product. For this operation please refer to the
technical characteristics of the product to
check the weight of the machine to be stocked
and act or proceed consequently.
m
ATTENTION DANGER OF POLLUTION
Once having taken the machine out of the
pallet or the container, do not dispose of it in
the environment, danger of pollution.
