Victoria Arduino Venus Family медь [58/64] Prodott
![Victoria Arduino Venus Family медь [58/64] Prodott](/views2/1321777/page58/bg3a.png)
40000008 VITE INOX M5X16 TESTA ESAGONALE ELLEN STAINLESS STEEL SCREW M5X16
40000009
VITE M5X8 OTTONE T. SVASATA A TAGLIO
BRASS SCREW M5X8
40200010 OR FLANGIA CALDAIA OR BOILER FLANGE VENUS FAMILY
40301001 CUPOLA VENUS FAMILY VENUS FAMILY DOME
40301002 CILINDRO VENUS FAMILY VENUS FAMILY CYLINDER
40301003 BASAMENTO BASE
40301004 GRIGLIA VENUS FAMILY VENUS FAMILY GRILL
40301005 VASCHETTA RACCOGLI ACQUA WATER DRAIN PLASTIC TANK
40301006 PIATTO A MEZZA LUNA GRILL-HOLDER PLATE
40301007 FRONTALINO VENUS FAMILY FRONTAL PANEL VENUS FAMILY
40301008 PIASTRINA TERMOSTATO THERMOSTAT PLAQUE
40401001 IMPIANTO ELETTRICO COMPLETO
COMPLETE ELECTRICAL PLANT
40500005 FERMACAVO VENUS CABLE-HOLDER
40500008
CALOTTA PROTEZIONE VENUS FAMILY
SAFETY CAP VENUS FAMILY
40600006 AQUILA EAGLE
40700031
PROLUNGA FISSA PROTEZIONE INOX
STAINLESS STEEL EXTENSION
40700037
ATTACCO RUB. LANCIA VAP. VENUS FAMILY
STEAM PIPE TAP
CONNECTION
40701001
FLANGIA CHIUSURA CALDAIA FAMILY MED.
BOILER FLANGE
VENUS FAMILY
40701002
RACC. TERMOST. CALDAIA VENUS MEDIA
BOILER THERMOSTAT FITTING
40701003 ATTACCO LANCIA VAPORE STEAM LANCE PLUG
40700101 MANOPOLA RUBINETTO VAPORE STEAM TAP HANDLE
40700102 MANOPOLA TERMOSTATO OTTONE BRASS THERMOSTAT HANDLE
40901002 RUBINETTO VAPORE VENUS FAMILY STEAM VALVE
40901004 SUPPORTO D16 D16 SUPPORT
40901005 TASTO BOMBATO BUTTON D16
40901006 LED VENUS FAMILY LED VENUS FAMILY
40901007 TERMOSTATO 130 THERMOSTAT 130
40901001 TERMOSTATO THERMOSTAT
47001001
TUBO COLLEGAMENTO CALDAIA ELETTROV
BOILER-SOLENOID VALVE TUBE
47001002
TUBO RUBINETTO VAPORE FAMILY MEDIA
STEAM TAP TUBE FAMILY
47301001 TELAIO COMPLETO VENUS FAMILY VENUS FAMILY COMPLETE FRAME
49801001
GRUPPO EROGAZIONE VENUS FAMILY
VENUS FAMILY GROUP
49901001 KIT LANCIAVAPORE STEAM LANCE
73012002
VALVOLA NEPLAX
EXPANSION VALVE
98005001 CORPO PORTAFILTRO CROMATO CHROMED FILTER HOLDER
98005015 PORTAFILTRO CROMATO COMPLETE FILTER HOLDER
98005016 MANOPOLA+TAPPO HANDLE+CAP
00000042 VITE M4X40 TCTCR SCREW M4X40
00000054 DADO M4 ALTO ZINCATO GALVANIZE NUT M4
40601001 PIASTRA VA PICCOLA SMALTATA DECORATIVE LOGO PLATE
Codice Descrizione Description
PRODOTTI / RICAMBI
Products / Spare parts
