INSTALLATION AND SET-UP
1_Assemble the eagle on the dome that is in the
accessories box.
2_Lift the dome and fill the white plastic container
with drinking water, then reassemble the dome.
3_ Connect the supply plug to an electric socket
with earthing.
4_
P
osition the vapour tube in correspondence to
the drip tray, then action the switch for the
coffee supply and at the same time open, by
rotating it, the vapour tap . When the water
comes out, turn the tap and wait for the water
to come out from the machine.
At this stage press the on/off switch for coffee
supply .
5_Hook the filter holder bowl with a movement
from left to right.
6_
Press the switch with the symbol “on/off”
and wait about five minutes (necessary time for
the machine preparation).
MAKING COFFEE
1_Take off the filter holder with a movement
from right to left. In the equipment there are
two filters (a bigger and a smaller one) and
two spouts ( a single and a double one). The
bigger filter will be used, together with the
double spout, for two coffees, while the
smaller filter together with the single spout,
will be used to make one coffee. The filter
holder spring must be inserted in the filter
holder.
For one coffee you will use the smaller filter filled
with a single measure from the measuring
spoon, for two coffees you will use the bigger
filter instead, filled with two measures of the
measuring spoon. Press the coffee with the small
press, then hook safely the filter holder with a
movement from left to right.
2_Place one or two cups in correspondence with
the exits of the filter holder and press the switch
for coffee supply; once you have the desired
quantity, press the on/off switch for coffee
supply .
USE OF THE VAPORISER
1_Turn the knob of the thermostat into
position .
