14
GB
Model
PURY-P700YSJM-A
PURY-P700YSJM-A1
PURY-P750YSJM-A PURY-P800YSJM-A
PURY-P800YSJM-A1
PURY-P850YSJM-A
PURY-P900YSJM-A
Noise level (50/60Hz)
63dB <A> 63dB <A> 63.5dB <A> 64dB <A> 64dB <A> 64.5dB <A> 65dB <A>
External static pressure
0 Pa *2
Indoor units
Total capacity
50~150% *1
Model
15~250
Quantity
2~50* 2~50* 2~50* 2~50* 2~50* 2~50* 2~50*
Operation
temperature
Standard type
Cooling mode: – 5°CDB ~ 46°CDB
Heating mode: – 20°CWB ~ 15.5°CWB
Fresh air intake type
Cooling mode: 21°CDB ~ 43°CDB
Heating mode: – 12.5°CWB ~ 20°CWB
Model
PURY-EP200YJM-A PURY-EP250YJM-A PURY-EP300YJM-A PURY-EP350YJM-A
PURY-EP400YSJM-A PURY-EP450YSJM-A PURY-EP500YSJM-A
Noise level (50/60Hz)
57dB <A> 60dB <A> 60dB <A> 61dB <A> 60dB <A> 62dB <A> 62dB <A>
External static pressure
0 Pa *2
Indoor units
Total capacity
50~150% *1
Model
15~250
Quantity
1~20 1~25 1~30 1~35 1~40 1~45 1~50*
Operation
temperature
Standard type
Cooling mode: – 5°CDB ~ 46°CDB
Heating mode: – 20°CWB ~ 15.5°CWB
Fresh air intake type
Cooling mode: 21°CDB ~ 43°CDB
Heating mode: – 12.5°CWB ~ 20°CWB
Model
PURY-EP500YSJM-A1
PURY-EP550YSJM-A
PURY-EP600YSJM-A
PURY-EP600YSJM-A1
PURY-EP650YSJM-A PURY-EP700YSJM-A
Noise level (50/60Hz)
63dB <A> 63dB <A> 63dB <A> 63.5dB <A> 63.5dB <A> 64dB <A>
External static pressure
0 Pa *2
Indoor units
Total capacity
50~150% *1
Model
15~250
Quantity
1~50* 2~50* 2~50* 2~50* 2~50* 2~50*
Operation
temperature
Standard type
Cooling mode: – 5°CDB ~ 46°CDB
Heating mode: – 20°CWB ~ 15.5°CWB
Fresh air intake type
Cooling mode: 21°CDB ~ 43°CDB
Heating mode: – 12.5°CWB ~ 20°CWB
* Connectable branch pipe number is max.48.
*1: The total indoor capacity of units run simultaneously is 150% or less.
*2: To enable high static pressure with (E)P200, (E)P250, (E)P300, (E)P350, P400, and P450, set the DipSW on the main panel as follows.
SW3-9: ON, SW3-10 60Pa compatible: OFF, 30Pa compatible: ON
5. Confi rmation of parts attached
This unit includes the following parts. Please check.
For usage methods, refer to item 10.2.
1 Connecting pipe
ID ø25.4, ID ø22.2
<Low-pressure side>
<High-pressure side>
2 Connecting pipe
ID ø25.4, OD ø19.05
<High-pressure side>
3 Connecting pipe
ID ø25.4, ID ø28.58
<Low-pressure side>
4 Connecting elbow
ID ø19.05, OD ø19.05
<High-pressure side>
5 Connecting elbow
ID ø28.58, OD ø28.58
<Low-pressure side>
Model P250YJM 1 pc. – – – –
P300YJM 1 pc. – – – –
P350YJM – 1 pc. 1 pc. 1 pc. –
P400YJM 1 pc. – 1 pc. – –
P450YJM 1 pc. – – – 1 pc.
EP250YJM 1 pc. 1 pc. – 1 pc. –
EP300YJM 1 pc. 1 pc. – 1 pc. –
EP350YJM – 1 pc. – 1 pc. 1 pc.
•
•
6. Space required around unit
1 In case of single installation
Secure enough space around the unit as shown in the fi gure on page 2.
[Fig. 6.0.1] (P.2)
<A> Top view <B> Side view
<C> When there is little space up to an obstruction
A
Front
B
Unit height
C
Back
D
Air outlet guide (Procured at the site)
(1) If the distance is 300 mm or more between the rear side and the wall
(2) If the distance is 100 mm or more between the rear side and the wall
(3) If the wall height (H) of the front, rear or side exceeds the wall height
restriction
When the height of the walls on the front, back or on the sides <H> exceeds
the wall height limit as defi ned here, add the height that exceeds the height
limit <h> to the fi gures that are marked with an asterisk.
If the unit cannot be kept clear of the wall, please change the direction of the
air outlet of the unit to blow against the wall to avoid air short cycle.
<Wall height limit> Front: Up to the unit height
Back: Up to 500 mm from the unit bottom
Side: Up to the unit height
•
•
•
(4) If there are obstacles at the upper part of the unit
2 In case of collective installation
[Fig. 6.0.2] (P.2)
A
Front
B
Must be open
C
Wall height (H)
When multiple units are installed adjacent to each other, secure enough
space to allow for air circulation and walkway between groups of units as
shown in the fi gures on page 2.
At least two sides must be left open.
As with the single installation, add the height that exceeds the height limit
<h> to the fi gures that are marked with an asterisk.
If there is a wall at both the front and the rear of the unit. Install up to six
units (three units: P450, EP350) consecutively in the side direction and
provide a space of 1000 mm or more as inlet space/passage space for each
six units (three units: P450, EP350).
•
•
•
•
WT05963X01_GB.indd 14WT05963X01_GB.indd 14 2010/08/26 20:39:442010/08/26 20:39:44
