![Mono Omega Plus 400 (твердое тесто) [10/70] Installation](/views2/1334008/page10/bga.png)
FG079 –OMEGA TOUCH INCL WIRECUT 09/12 RAC
10
5.0 INSTALLATION
1 Ensure that the depositor is connected to correct electric supply, as specified on the
serial number plate on the side of the machine.
2 Ensure that the correct fuse rating is fitted in the electrical supply
6.0 ISOLATION
IN AN EMERGENCY, SWITCH OFF AT THE
ELECTRICAL MAINS WALL ISOLATOR, OR
PUSH THE EMERGENCY STOP BUTTON.
To release the emergency stop button, turn clockwise.
STOP BUTTON
Omega
PLUS
