FG079 –OMEGA TOUCH INCL WIRECUT 09/12 RAC
31
EXAMPLE:
“C” SHAPE
(ARC)
DEPOSIT QUANTITY
DURING ROTATION
NOZZLE HEIGHT
ABOVE TRAY
SURFACE
NOZZLE ROTATION
(NUMBER OF TURNS
DURING DEPOSIT)
RED TRAY SETUP BUTTON
FORCES USER TO ENTER AND
CHECK TRAY SETUP VALUES
(OTHER BUTTONS GREYED OUT)
DEPOSIT QUANTITY
FOR END OF
PRODUCT
(-VE VALUES POSSIBLE)
RADIUS (mm)
OF DEPOSIT
GO TO
PART
5A
DEPOSIT QUANTITY
FOR BEGINNING OF
PRODUCT
(-VE VALUES POSSIBLE)
