FG079 –OMEGA TOUCH INCL WIRECUT 09/12 RAC
6
2.0 DIMENSIONS
Omega
PLUS
890mm
690mm
1210mm
856mm
470mm
1330mm
1510mm
898mm MAX
818mm MIN
1451mm (extended capacity hopper)
1981mm (400mm + 450mm Extended capacity hopper)
WIRECUT
MODELS ARE AVAILABLE WITH OR WITHOUT WIRECUT OPTION
