FG079 –OMEGA TOUCH INCL WIRECUT 09/12 RAC
4
CONTENTS
1.0 - INTRODUCTION
2.0 - DIMENSIONS
3.0 - SPECIFICATIONS
4.0 - SAFETY
5.0 - INSTALLATION
6.0 - ISOLATION
7.0 - CLEANING INSTRUCTIONS
8.0 - OPERATING CONDITIONS
9.0 - PREPARING FOR OPERATION
9A – FITTING THE HOPPER
9B – FITTING A TEMPLATE
10.0 - OPERATING INSTRUCTIONS
1 – SELECT PRODUCT TYPE
2 – SELECT SAVED NAME OF PRODUCT TYPE
3 – CONFIRM SETUP
4 – OPERATOR SCREEN
5 – EDIT SCREEN
5A – TRAY SETUP
6 – COPY
7 – DELETE
8 – PASSWORDS
9 – ENGINEERING SETTINGS
10 – FAULT INFORMATION SCREENS
11.0 - MAINTENANCE CHECK AND MAINTENANCE SCHEDULE
12.0 - SPARES AND SERVICE
13.0 - SPARES LIST
14.0 - ELECTRICAL INFORMATION
Omega
PLUS
