NORMA-S IDRO DSA / STEEL / CLASSIC
18 7197130s - IT-EN-DE-FR
2. TECHNICAL DATA
Denition in accordance with EN 13240
Constructive system
Global thermal power in kW
Nominal thermal power in kW
Power given back to water in kW
Power given back to the room in kW
Hourly wood consumption in kg/h (wood with 20% humidity)
Efciency in %
CO measured at 13% oxygen in %
Smoke outlet diameter in mm
Chimney height - dimension in mm (#)
Fluid contents of the exchanger (H
2
O) in L (litres)
Chimney draught in Pa (mm H
2
O)
Boiler connections (Ø)
Automatic discharge pipe diameter (Ø)
Outer air inlet Ø in mm (minimum surface cm
2
)
Exhaust gas emission in g/s – wood
Exhaust gas temperature in °C - wood
Optimal working temperature in °C
Max. working pressure in bar (expansion vessel )
Hearth opening size in mm (W x H)
Hearth size in mm (W x H x D)
Oven size in mm (W x H x D)
Type of grill
Movable - at
Height in mm
Width in mm
Depth in mm
Weight in Kg
Fire prevention safety distances
Chapter FIRE SAFETY
heatable m
3
(30 kcal/h x m
3
) (# #)
(#) 200 mm diameter can be used with ue of no less than 6 m.
(# #) For those buildings in which the thermal insulation does not correspond to the instructions on heat protection, the heating volume
of the product is: favourable type of building (30 Kcal/h x m
3
); less favourable type of building (40 Kcal/h x m
3
); unfavourable type of
building (50 Kcal/h x m
3
).
With thermal insulation in accordance with the regulations regarding energy saving, the heated volume is greater. With temporary heating,
in the event of interruptions which last more than 8 hours, the heating capacity is reduced by about 25%.
IMPORTANT: The power of the connected heating system must be proportional to the power transferred to the water by the thermoproduct;
a charge which is too low does not allow regular oven operation, while a charge which is too high prevents adequate radiator heating.
3. GENERAL PRECAUTIONS
La NORDICA S.p.A. responsibility is limited to the supply of the appliance.
The installation must be carried out scrupulously according to the instructions provided in this manual and the rules of the profession.
Installation must only be carried out by a qualied technician who works on behalf of companies suitable to assume the entire responsibility
of the system as a whole.
La NORDICA S.p.A. declines any responsibility for the product that has been modied without written authorisation as well as
for the use of non-original spare parts. NO MODIFICATIONS CAN BE CARRIED OUT TO THE APPLIANCE. La NORDICA S.p.A.
cannot be held responsible for lack of respect for such precautions.
It is OBLIGATORY to respect the National and European rules, local regulations concerning building matter and also reproof
rules.
4. INSTALLATION REGULATIONS
Installation of the product and auxiliary equipment in relation to the heating system must comply with all current Standards and Regulations
and to those envisioned by the law.
The installation and the relating to the connections of the system, the commissioning and the check of the correct functioning must
be carried out in compliance with the regulations in force by authorised professional personnel with the requisites required by the law,
NORMA- S IDRO -
DSA
NORMA - S IDRO
Steel - DSA
NORMA Classic - S
IDRO - DSA
1 1 1
24,8 24,8 24,8
19,5 19,5 19,5
14,9 14,9 14,9
4,6 4,6 4,6
5,8 5,8 5,8
78,6 78,6 78,6
0,09 0,09 0,09
160 160 160
5m – 220x220 Ø220
40 40 40
17 - 20 (1,7 - 2,0)
1 ”F gas 1 ”F gas 1 ”F gas
½”M gas ½”M gas ½”M gas
200 (100 cm
2
) 200 (100 cm
2
) 200 (100 cm
2
)
17,5 17,5 17,5
250 250 250
70 -75 70 -75 70 -75
VEA 1,5 bar - VEC 2,5 bar
424 x 350 424 x 350 424 x 350
424 x 450 x 320 424 x 450 x 320 424 x 450 x 320
/ / /
1242 1272 1272
720 766 766
575 589 589
249 244 259
559 559 559
