MODULO ALL INCLUSIVE

7095520 - IT-EN-DE-FR 13

6.5. EXCESS TEMPERATURE ALARM

When the temperature measured by the water probe exceeds 87°C / 188.6°F (xed threshold set), this alarm is activated, starting the

circulating pumps.

When the alarm is activated, LED 1 Danger comes on and the message “EXCESS TEMPERATURE” is shown on the display.

6.6. FAULTY PROBE ALARM

When a probe fault occurs, this alarm is activated, starting the circulating pumps.

When the alarm is activated, LED 1 Danger comes on and the message “FAULTY PROBE” is shown on the display.

6.8. SETTINGS MENU

See Chapter 13.

Pressing and holding the MENU button (T4) accesses the LANGUAGE menu. (Press T1 to exit the menu).

Press the MENU button again briey to modify the language displayed (IT; EN; DE; FR) using the T2-T3 buttons. Press MENU to conrm

the selection.

Press the T2 button to access the BUZZER menu (enable the audible signal). Press the MENU button to enable or disable the buzzer using

the T2-T3 buttons (ON / Off). Press MENU to conrm the selection.

Press the T2 button to access the SET DEGREES menu (display the temperature in °C / °F). Press the MENU button to modify, using the

T2-T3 buttons, the temperature display from °C to °F and vice-versa. Press MENU to conrm the selection.

Press the T2 button to access the DISPLAY menu (brightness from 0 to 100). Press the MENU button to set the required display brightness,

This application is useful when the All Inclusive UNIVERSAL module is not installed near the thermoproduct it is associated with.

The digital regulator installed in the All Inclusive UNIVERSAL module is managed by the remote regulato (ONLY included in ther standard

supply of the UNIVERSAL module) which has identical functions.

When the two digital regulators are connected to each other, the lighting of both screens will be less bright. This phenomenon is completely

normal and has been designed specically to stop the screens from overheating.

IMPORTANT: the ambient temperature is displayed on the remote screen followed by the letter “A”, while the temperature of the water in

the boiler is followed by the letter “R”. The thermoproduct boiler water temperature probe (l1) must be connected directly to the remote

digital regulator. The probe cable can have a maximum length of 5 metres.

IMPORTANT: the digital regulator installed in the All Inclusive UNIVERSAL module must be connected to the remote digital regulator, as

shown in Picture 2 at page 24, through a bipolar electric cable (NOT included), with a length that does exceed 100 metres

9. SUMMER SET ASIDE

ATTENTION: the installation must be kept constantly full of water even in periods in which the use of thermoreplaces is not required.

During winter time, inactivity must be faced by adding antifreeze substances.

OPEN expansion VESSEL system: check the water level in the expansion tank and remove any air from the system by bleeding the

radiators; also check to make sure that the plumbing and electrical accessories (control unit, circulator) are working properly..
