6INSTALLATION AND ASSEMBLY

POSITIONING

The FORMA WOOD closed replace may be positioned both at an angle or against a wall. One can customise it with the manufacturer's

claddings or build them on site with materials resistant to high temperatures.

The closed replaces are freestanding units that simplify installation and that do not require any additional support. To facilitate moving

the unit to the point in which it must be installed, the manufacturer supplies the closed replace with four swivel wheels that make

moving the closed replace easier and not tiring. (gure 2)

Once the closed replace has been positioned, the wheels must be lifted from the ground or removed, so that the unit is stable on the oor.

This is possible by adjusting the four feet pre-mounted on the closed replace.

Always assess the static conditions of the surface on which the weight of the product will rest and always leave a gap of

at least 5 cm between the chimney and walls.

Dry mount the hearth of the cladding, leaving a 1 cm gap for insulation. (Figure 3)

FORMA WOOD

75 DX-SX

95 DX-SX

T95

T50

Non-ammable walls Flammable walls

A = 50 mm

B = --------

C = 40 mm

A = 100 mm

B = 40 mm

C = 80 mm

A = distance from the side and rear walls

B =insulating material

C = height from oor

If the closed replace is positioned on a oor or in proximity of ammable walls one recommends suitable insulation.

The hot air outlet vents must be positioned at least 300 mm away from other materials. (e.g. curtains)

FIGURE 2 – WHEELS AND FEET FIGURE 3 – DISTANCE OF THE UNIT FROM THE WALLS

AND FROM THE CLADDING
