MCZ Forma 75 dx [34/40] Operation

7-OPERATION

FIGURE 13 - HEARTH DOOR OPENING / CLOSING (FORMA T95)

The closed replace package contains a handle that can be installed on the door (as per instructions supplied with

the handle).

COMBUSTION CONTROL

PRIMARY AIR

Primary air enters directly via the openings present between the casing and structure of the closed replace. This air enables combustion.

My moving the supplied lever to the right as shown in the gure, one has full opening with faster combustion while if it is moved to the

left one has closure with slower combustion.

The lever turned towards MAX is designed to bring a large quantity of primary air beneath the replace hearth, to allow rapid and eective

ignition of the re.

Air for cleaning the glass enters directly from the door with a xed passage section, both in MAX and MIN combustion modes.

FIGURE 14 - ADJUSTMENT OF PRIMARY/SECONDARY AIR
