6-INSTALLATION AND ASSEMBLY

HEIGHT AND LEVEL ADJUSTMENT

The Forma Wood closed replace is equipped with adjustment feet which enable to adjust the level of the closed replace hearth by

approximately 2/3 cm.

If one wishes to raise the closed replace by over 2/3 cm one must create a brickwork pedestal on which to place the product.

In any case do not remove the feet that are essential for levelling.

Removing the feet is considered a structural modication of the product and therefore it makes the warranty void.

Levelling the closed replace is an essential operation for the hearth door to slide properly.

In the event of a oor made of ammable material, the lower part of the closed replace (C) must be at least 5 cm

away from the oor. Fig.4

CHECK THE DOOR SLIDING SEVERAL TIMES BEFORE CLOSING THE FIREPLACE WITH THE CLADDING.

If the closed replace is not positioned level, there is a risk that the door does not close properly and that the internal

counterweights knock against the structure causing noise every time one lifts and lowers the door.

It is recommended to use the wheels (supplied) when one must move the closed replace; the feet are then sucient for levelling.

FIGURE 4 - SAFETY MEASURES
