LEVELLING THE HOOD

• The hood canopy must be levelled.

• The Hood is levelled by adjusting the

safety pawls C.

• Rest a spirit level on the hood.

• Exerting an upwards pressure on the safety knobs

“

unlocks” movement of the Cable. By inserting or

extracting the cable from the cable locking screw

it is possible to make adjustments to level the

mobile hood canopy.

• Once the hood has been set level, the safety knobs

must be tightened.

Warning:

• Make sure that all 4 of the support cables are taut.

• Make sure that none of the 4 support cables have been damaged during installation.

• Remember that there must be a minimum distance of 650mm between the Hood and the cooker

hob and the maximum extension of movement must not exceed 645mm.
