HP 14-am012ur (Z3C61EA) [24/99] Chapter 3 illustrated parts catalog
![HP 14-am012ur (Z3C61EA) [24/99] Chapter 3 illustrated parts catalog](/views2/1349826/page24/bg18.png)
Item Component Spare part number
(1) Display assembly, 14.0 in (35.56 cm), high definition (HD), WLED, SVA BrightView
NOTE: The display assembly is spared at the subcomponent level only.
not spared
(2) Keyboard (includes keyboard cable):
Latin America 785871-161
United States 785871-001
(3) Top cover (includes TouchPad and cable): 785295-001
(4) Power button board (includes cable) 785287-001
(5) TouchPad button board (includes cable) 734418-001
(6) Power connector bracket is available with the power connector cable, spare part number 732067-001
(7) USB/audio board (includes cable) 734417-001
(8) Hard drive (does not include hard drive rubber bracket, hard drive connector cable, or screws):
1 TB, 5400 rpm, 9.5 mm 778192-005
500 GB, 5400 rpm, 7.0 mm 669299-005
Hard Drive Hardware Kit, includes: 740706-001
(9) Rubber bracket
(10) Hard drive connector
(11) System board (includes replacement thermal material):
AMD A4-5000 for use in models without the Windows operating system 785293-001
AMD A4-5000 for use with Windows 8.1 Standard 785293-501
AMD E1-2100 processor for use in models without the Windows operating system 785292-001
AMD E1-2100 processor for use with Windows 8.1 Standard 785292-501
(12) Fan 732068-001
(13) RTC battery 697917-001
(14) Heat sink assembly (includes replacement thermal material): 776776-001
(15) Power connector cable (includes bracket): 732067-001
(16) Memory modules (2), (PC3L, 12800, 1600 MHz):
2 GB memory module 691739-001
4 GB memory module 691740-001
(17) WLAN module:
Realtek RT8723BE 802.11bgn 1x1 Wi-Fi + BT4.0 Combo Adapter 753077-001
Realtek RTL8188EE 802.11 bgn Wi-Fi adapter 709848-001
(18) Speakers (include subwoofer, speaker cables, and rubber isolators) 734422-001
(19) Battery
4 cell, 41 Whr, 2.8 Ah, Li-ion battery 752237-001
14 Chapter 3 Illustrated parts catalog
