![HP 14-am012ur (Z3C61EA) [57/99] Power button board](/views2/1349826/page57/bg39.png)
Power button board
Description Spare part number
Power button board (includes cable) 785287-001
Before removing the power button board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 25), and then remove the following components:
a. Service door (see
Service door on page 26)
b. Memory module (see
Memory module on page 28)
c. WLAN module (see
WLAN module on page 30)
d. Optical drive (see
Optical drive on page 32)
e. Keyboard (see
Keyboard on page 34)
f. Top cover (see
Top cover on page 41)
Remove the power button board:
1. Position the top cover upside down with the front toward you.
2. Remove the Phillips PM2.5×2.5 screw (1) that secures the power button board to the top cover.
Component replacement procedures 47
