Miscellaneous parts
Component Spare part number
45 W HP Smart AC adapter (nPFC, RC, 3-wire, 4.5 mm) 741727-001
Power cord (3 pin, black, 1.83 m):
For use in the United States 755530-001
For use in Argentina 755530-D01
For use in India 755530-D61
For use in Italy 755530-061
Screw Kit 785291-001
Sequential part number listing
Spare part number Description
669299-005 500 GB, 5400 rpm hard drive (SATA, 7.0 mm, does not include hard drive rubber bracket, hard drive
connector cable, or screws)
NOTE: The hard drive rubber bracket, hard drive connector cable, and screws are included in the Hard
Drive Hardware Kit, spare part number 740706-001.
691739-001 2 GB memory module (PC3, 12800, 1600 MHz)
691740-001 4 GB memory module (PC3, 12800, 1600 MHz)
697917-001 RTC battery
709848-001 Realtek RTL8188EE 802.11 bgn Wi-Fi Adapter
732067-001 Power connector cable (includes bracket)
732068-001 Fan
734407-001 Display panel cable (includes (includes webcamera/microphone module cable and screws )
734408-001 Display Hinge Kit (includes left and right hinges and screws)
734417-001 USB/audio board (includes cable)
734418-001 TouchPad button board (includes cable)
734422-001 Speakers (include subwoofer, speaker cables, and rubber isolators)
740706-001 Hard Drive Hardware Kit (includes hard drive rubber bracket, hard drive connector cable, and screws)
741727-001 45 W HP Smart AC adapter (nPFC, RC, 3-wire, 4.5 mm), nslim
752237-001 4 cell, 41 Whr, 2.8 Ah, Li-ion battery
753077-001 Realtek RT8723BE 802.11bgn 1x1 Wi-Fi + BT4.0 Combo Adapter
755530-001 Power cord for use in North America (3 pin, black, 1.83 m)
755530-061 Power cord for use in Italy (3 pin, black, 1.83 m)
755530-D01 Power cord for use in Argentina (3 pin, black, 1.83 m)
Miscellaneous parts 17
