Hard drive
NOTE: The hard drive spare part kit does not include the hard drive rubber bracket, hard drive connector
cable, or screws. These components are included in the Hard Drive Hardware Kit, spare part number
740706-001.
Description Spare part number
1 TB, 5400 rpm, 9.5 mm 778192-005
500 GB, 5400 rpm, 7.0 mm 669299-005
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 25), and then remove the following components:
a. Service door (see
Service door on page 26)
b. Memory module (see
Memory module on page 28)
c. WLAN module (see
WLAN module on page 30)
d. Optical drive (see
Optical drive on page 32)
e. Keyboard (see
Keyboard on page 34)
f. Top cover (see
Top cover on page 41)
Remove the hard drive:
1. Disconnect the USB/audio cable (1) by flipping open the connector and lifting the cable. Remove the
USB/audio cable Phillips M 2.5×3.0 screw (2) and then lift the USB/audio board (3). The USB/audio board
spare part number is 734417-001.
44 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
