rather than to do the entire job with one pass. A gentle touch
gives the best control and reduces the chance of error.
HOLDING THE TOOL
For best control in close work, grip the multitool like a pencil


grinding or cutting. PICTURE 14
OPERATING SPEEDS
To select the right speed for each job, use a practice piece of
material.


top side of the motor housing.


HIGH PERFORMANCE MOTOR
Your tool is equipped with a high performance rotary tool motor.
This motor expands the versatility of the rotary tool by driving
additional Dremel attachments.
ELECTRONIC FEEDBACK
Your tool is equipped with an internal electronic feedback

stresses that occur from a high torque start. The system also
helps to keep the preselected speed virtually constant between
no-load and load conditions.
VARIABLE SPEED DIAL
Your tool is equipped with a variable speed dial. The speed
may be adjusted during operation by presetting the dial on or
between any one of the settings.
The speed of Rotary Tool is controlled by setting this dial on the
housing. PICTURE 12
Settings for Approximate Revolutions
200 Model
Switch Settings Speed Range (RPM)
Low 15,000
High 35,000
3000 Model
Switch Settings Speed Range (RPM)
1-2 10,000-14,000
3-4 
5-6 20,000-23,000
7-8 24,000-28,000
 
4000 and 4200 Model
Switch Settings Speed Range (RPM)
5 5,000
10 10,000
*15 15,000
20 20,000
25 25,000
30 30,000
33 (4000 only) 33,000
35 (4200 only) 35,000
* Do not exceed 15,000 RPM when using wire brushes.
Refer to the Speed Settings chart on pages 4-7 to help
determine the proper speed for the material being worked on
and the accessory to use.
Most jobs can be accomplished using the tool at the highest
setting. However, certain materials (some plastics and metals)
can be damaged by high-speed generated heat and should
be worked on at relatively low speeds. Low speed operation
(15,000 RPM or less) is usually best for polishing operations
employing the felt polishing accessories. All brushing
applications require lower speeds to avoid wire discharge from
the holder. Let the performance of the tool do the work for you
when using lower speed settings. Higher speeds are better for
hardwoods, metals and glass and for drilling, carving, cutting,
routing and shaping.
Some guidelines regarding tool speed:
• Plastic and other materials that melt at low temperatures
should be cut at low speeds.
• 
done at speeds no greater than 15,000 RPM to prevent
damage to the brush and your material.
• Wood should be cut at high speed.
• Iron or steel should be cut at high speed.
• If a high speed steel cutter starts to vibrate, it usually
indicates that it is running too slowly.
• Aluminium, copper alloys, lead alloys, zinc alloys and tin
may be cut at various speeds, depending on the type of

suitable lubricant on the cutter to prevent the cut material
from adhering to the cutter teeth.
NOTE: Increasing pressure on the tool is not the answer when
it is not performing properly. Try a different accessory or speed
setting to achieve the desired result.
MAINTENANCE AND REPAIR
!
WARNING
ALWAYS UNPLUG THE TOOL FROM THE
POWER SOURCE BEFORE YOU MAKE
ANY ADJUSTMENTS, CHANGE ACCESSORIES, SERVICE,
CLEAN, ETC. THIS REDUCES THE RISK OF STARTING THE
TOOL ACCIDENTALLY.
!
WARNING
HAVE YOUR POWER TOOL SERVICED
BY A QUALIFIED REPAIR PERSON WHO
USES ONLY IDENTICAL REPLACEMENT PARTS. WE
RECOMMEND THAT ALL TOOL SERVICE BE PERFORMED BY
A DREMEL SERVICE CENTRE. THIS WILL ENSURE THE
SAFETY OF THE TOOL. MAINTENANCE PERFORMED BY
UNAUTHORIZED PERSONNEL CAN RESULT IN INCORRECT
CONNECTION OF INTERNAL WIRING AND COMPONENTS
WHICH CAN CAUSE SERIOUS HAZARD.
NOTE
You can only inspect and replace the carbon brushes. There
are no other serviceable parts inside the tool.
CLEANING
1. Clean ventilation openings, switch and levers of the tool
with compressed dry air.
!
WARNING
DO NOT CLEAN THE TOOL BY
INSERTING POINTED OBJECTS
THROUGH AN OPENING.
!
WARNING
WEAR SAFETY GOGGLES TO PROTECT
YOUR EYES.
2. Clean the surface of the tool with a damp cloth.
21
