6
GB
F D E
English
I P NL S DK N FIN GR H CZ RUS RO PL
INSTRUCTIONS FOR SAFE HANDLING
■ Make sure that the tool is only connected to the
voltage marked on the name plate.
■ Never use the tool if its cover or any bolts are missing.
If the cover or bolts have been removed, replace them
prior to use. Maintain all parts in good working order.
■ Always secure tools when working in elevated
positions.
■ Never touch the blade, drill bit, grinding wheel or
other moving parts during use.
■ Never start a tool when its rotating component is in
contact with the work piece.
■ Never lay a tool down before its moving parts have
come to a complete stop.
■ ACCESSORIES: The use of accessories or
attachments other than those recommended in this
manual might present a hazard.
■ REPLACEMENT PARTS: When servicing use only
identical replacement parts.
BELT SANDER SAFETY PRECAUTIONS
■ Hold the tool firmly with both hands.
■ Keep the cord away from the rotating abrasive belt.
■ Keep your hands away from rotating parts.
■ Do not place the tool on a surface while the belt is still
moving since belt rotation will cause it to move,
and may result in the tool being damaged or personal
injury.
■ The tool must be used only for dry sanding.
■ Do not continue to use worn or torn abrasive belts.
■ Clamp the work piece if it does not remain stationary
due to its own weight.
■ Turn the tool on before applying it to the work piece.
■ Turn the tool off after it has been lifted away from the
work piece.
STANDARD ACCESSORIES
Dust bag, Abrasive belt.
OPTIONAL ACCESSORIES
G-Clamp, Sanding frame.
APPLICATIONS
Use only for the purpose listed below:
1. Surface finishing for wood.
2. For removal of rusl and surface finishing for metal.
NOISE BUILD-UP
Noise (sound pressure level) in the workplace can exceed
85 dB(A). In this case, sound insulation and hearing
protection measure must be taken by the operator.
SWITCH (FIG. 1)
This tool is started and stopped by squeezing and
releasing the trigger (8/18).
For continous operation, press the lock-on button (7/17)
while trigger is being squeezed. Squeeze trigger again to
release the lock.
The belt speed can be freely adjusted from 240 to
400 m/min by turning the speed adjusting dial (20)
(EBS-9576V / EBS-1310V)
(A = lowest speed / F = highest speed)
DUST BAG (FIG. 2)
When sanding wood, the dust bag (5/15) should be used.
Although the dust bag has a substantial capacity,
it should be emptied frequently.
Opening the zipper of the dust bag allows complete
cleaning.
CAUTION!
When sanding metal, the dust bag should not be
used, because of the risk of fire from flying sparks.
CHANGING THE ABRASIVE BELT (FIG. 3 TO 5)
WARNING!
BE SURE TO DISCONNECT THE TOOL FROM
THE POWER SUPPLY WHEN MOUNTING AND
REMOVING THE SANDING BELT.
■ Place the tool on its side and lift the lever (3/13)
to retract the front roller and release the belt tension
(Fig. 3).
■ Pull the sanding belt off.
If the belt tension is not released after lifting the lever,
loosen the adjustment knob (9/19) (Fig. 4).
■ Mount a new sanding belt.
BELT SANDER -MANUAL 4/08/03 9:30 Page 6
