BELT SANDER MANUAL 4 08 03 9 30 Paa 7 English MOUNTING ADJUSTING THE OPTIONAL SANDING FRAME FOR EBS 7576 ONLY FIG 8 CHANGING THE ABRASIVE BELT FIG 3 TO 5 NOTE Be sure that the arrow inside of the belt is pointing in the same direction as that of the tool Put the sanding frame on the belt sander and attach four slot into slot holder 25 Push the lever down to the original position Fig 5 A By turning the adjustment bolt counterclockwise the sanding frame will rise and can be taken out If turning clockwise it will down and the depth will be added CAUTION Ensure that your fingers are not trapped Fine adjustment of the abrasive action is possible by turning the adjustment bolt 24 TRACKING ADJUSTMENT FIG 6 The belt life will be increased by using the tracking adjustment Turn the tool upside down and hold if firmly with one hand then start the tool and observe the tracking of the sanding belt Stop the tool and adjust the tracking of the belt by rotating the tracking knob until the edge of the belt is even with the outer edges of both the front and rear rollers A MOUNTING ADJUSTING THE OPTIONAL SANDING FRAME FOR EBS 9576V EBS 1310V ONLY FIG 9 Put the belt sander on the sanding frame and attach four slot into slot holder 25 By turning the adjustment bolt counterclockwise the sanding frame will down and can be taken out If turning clockwise it will raise and the depth will be added CAUTION Check that the belt does not rub against the tool s frame Fine adjustment of the abrasive action is possible by turning the adjustment bolt 24 OPERATING FIG 7 MAINTENANCE NEVER COVER AIR VENTS SINCE THEY MUST ALWAYS BE OPEN FOR PROPER MOTOR COOLING MAKE SURE THAT THE WORK PIECE IS FREE OF NAILS AND OTHER FOREIGN OBJECTS THAT COULD TEAR THE ABRASIVE BELT After use check the tool to make sure that it is in top condition It is recommended that you take this tool to a Ryobi Authorized Service Centre for a thorough cleaning and lubrication at least once a year Hold the tool firmly with both hands Turn the switch on and permit the rotation of the abrasive belt to reach full speed Then gently place the tool on the work piece surface Move the tool back and forth Never exert excessive pressure on the tool The weight of the tool applies adequate pressure Excessive pressure will retard the abrasive action leave an uneven finish and cause extra wear to both the tool and the abrasive belt Always lift the tool off the work piece before turning the switch off DO NOT MAKE ANY ADJUSTMENT WHILE THE MOTOR IS IN MOTION ALWAYS DISCONNECT THE POWER CORD FROM THE RECEPTACLE BEFORE CHANGING REMOVABLE OR EXPENDABLE PARTS BLADE BIT SANDING PAPER ETC LUBRICATING OR WORKING ON THE UNIT A CLAMP Optional accessory The clamp is designed to stabilize the tool when using it in the bench configuration WARNING To ensure safety and reliability all repair should be performed by an AUTHORIZED SERVICE CENTRE or other QUALIFIED SERVICE ORGANIZATION SAVE THESE REFERENCE 7 INSTRUCTIONS FOR FUTURE
