NOTICE
This function is relative with the model and parameter
of the camera module which insert in the dome. The option
is useless(N/A)when the camera module has nosuch function.
5. 1. 5 WDR Control
LENS PARAMETERS
ZOOMSPEEDHIGH
DIGITALZOOMON
BLCMODEOFF
SLOWSHUTTERON
WDRMODEN/A
MIRRORON
FLIPON
DAY/NIGHTSETTING
BACK
EXIT
【 】Operate joystick and move the cursor to WDR MODE , press
OPEN , tilt up/down joystick to set WDR. Choose ON means 【 】
open WDR, choose OFF means close WDR, press OPEN to save.【 】
WDR MODE : WDR is the function that features of image can be 【 】
captured clearly by camera while the picture was cover with strong
contrast background. For example: you can enable WDR function to
sublime image quality when the two areas A and B exist simultaneo-
usly, A: High intensity area under strong light exposure (source from
daylight, lamp and so on), B: Low luminance area, like shadow,
backlighting zone and so on.
4. MIRROR : image mirroring function. 【 】
5. FLIP : 180° inversion imaging function of image. 【 】
CAMERA SETTING
LENSPARAMETERS
AEMODESETTING
AWEMODESETTING
ADVANCEPARAMETERS
PRIVACYMASK
BACK
EXIT
2 5
MAIN MENU
SYSTEMSETTING
CAMERASETTING
FUNCTIONSETTING
DISPLAYSETUP
EXIT
5. 1. 6 Day/night setting
1. The system enters into the main menu by calling 95 preset or by
calling 9 preset twice within 3 seconds.
. Operate the joystick up and down and move the cursor to CAM-2 【
ERA SETTING to enter submenu.】
. Operate the joystick up and down and move the cursor to LENS 3 【
PARAMETERS , press OPEN to enter , 】 【 】 【DAY/NIGHT SETTING】
the cursor jumps to right, there are three choices of "DAY/NIGHT",
which is as follows:
●【AUTO】: IR cut filter mode, it means the dome
automatically transfers according to sensitivity.
●【TIME】: set the time of opening IR cut filter
●【COLOR】: set as color mode
●【BLACK】 : set as black and white mode
4 【 】. THRESHOLD :sensitive of IR cut filter, the range from 0 to
28dB.
5. Press OPEN to save.【 】
OPERATION KNACKS
NOTICE
IR cut filter function uses color in day; use black and white at
night. This function not only guarantees the quality of image, but
also saves the room of storage.
This function depends on the models and parameters
of built-in camera in dome, if the camera haven't this
function, then this function is invalid.(N/A)
DAY/NIGHTTIME
DAYTIME00:00
NIGHTTIME00:00
THRESHOLD10dB
BACK
EXIT
DAY/NIGHT SETTING
LENS PARAMETERS
ZOOMSPEEDHIGH
DIGITALZOOMON
BLCMODEOFF
SLOWSHUTTERON
WDRMODEN/A
MIRRORON
FLIPON
DAY/NIGHTSETTING
BACK
EXIT
2 6
MAIN MENU
SYSTEMSETTING
CAMERASETTING
FUNCTIONSETTING
DISPLAYSETUP
EXIT
