Clatronic CL 3134 [18/22] Initial operation

ENGLISH

Unpacking the appliance

• Remove the appliance from the box and all the enclosed

accessories.

• Do not through the packaging away, but keep it together with

the inner packing and the warranty documents for the whole

life of the warranty.

• Place the appliance on smooth, level and stable work

surface.

• Do not insert the appliance plug without installing the

necessary attachments.

Installation

Installing the Exhaust Air Hose

• Place the connection ring (11) over the exhaust air hose

(10). Turn the connection ring at least ﬁ ve times in a clockwi-

se direction until it is tight. Check that it cannot be pulled off.

• Push the assembled exhaust air hose from right to left

over the hose connection (9) on the back. Guide it into the

holders until it locks in place. In order to release the hose

again, press in the right-hand retainer and push the hose to

the right out of the holder.

 NOTE:

If the device is in „cooling“ mode the end of the exhaust air

hose has to be led out of the air-conditioned room.

Initial Operation

• Only connect the machine to a properly installed safety

socket, 230 V/50 Hz.

• Make sure that the degree of protection of the socket to

which the device is connected is of at least 10 ampere!

• Place the device on any heat-resistant ﬂ at surface. Ensure

that air can enter and leave unhindered.

• The distance from the air inlet grille (5/7) to the nearest wall

should be at least 20 cm. The distance from the air outlet

grille (2) to the nearest wall should be more than 1m.

Switching on/off

1. As soon as you have inserted the plug the mains control

lamp (J) lights up in red and indicates that the device is

connected to the mains.

2. Press the „ “ button (J) (13 on the remote control) to switch

the device on - the control lamp lights up in green. An

acoustic signal is heard and the digital display (E) shows

22 °C.

The device switches to the highest speed and the

„cooling“

mode (the „

“ control lamp lights up in red

and the

„

“

con

trol lamp in green). The air outlet (2) opens.

After a few seconds the device switches on automatically.

Please wait until the device has begun operation.

 NOTE:

Changing the Mode of Operation

When the mode of operation is changed the compressor

remains switched off for approximately 6 minutes until the

pressure in the refrigeration circuit has eased.

Then the compressor switches on again automatically.

Cooling

• If you would like to change the room temperature using the

„cooling“ mode of operation, press the „

왔

“ or „

왖

“ button

(D/F). The digital display (E) shows the temperature (min.

18°C – max. 32°C). The temperature increases or reduces

by 1°C with each press of the button.

• By repeatedly pressing the „

“ button (1

) on the remote

control you can switch from 18, 19, 20.....32; from there it

returns to 18, 19 etc.

• The device cools the room down to the set temperature,

which it then maintains. If the set temperature is above the

current room temperature, the device switches the cooling

off and only the ventilator continues running.

 NOTE:

The rate at which the desired temperature is reached depends

on the temperature of the room and the outside temperature.

Ventilator Speed

In the „cooling“ and „ventilator“ modes it is possible to set 3 dif-

ferent levels for the speed of the ventilator. The speed changes

with each press of the „

“ button (G/15):

Red – for a high speed

Green – for a medium speed

Orange – for a slow speed

Timer Functions

Switch-off Timer

1. Turn the device on with the „ “ button (J/13).

2. Brieﬂ y press the „ “ button (B/17) to change over to timer

adjustment. The digital display on the control panel ﬂ ashes

and shows 00. The „ “ control lamp lights up in green.

3. Press the button repeatedly to programme the timer. The

length of time is increased with every press of the button by

1 hour (00, 01, 02.....24, then from the beginning again).

4. After the set time has expired the device switches off.

Switch-on Timer

Before you use the switch-on timer turn the device on and set

the mode of operation, the ventilator speed and temperature.

05-CL 3134 18 14.12.2007, 14:17:32 Uhr

Mode of Operation

Press the „

“ button (H/14) to switch the mode of operation bet-

ween “cooling” (green), „dehumidiﬁ er” (orange) and “ventilator“

(no lamp).

Mains Lead Take-up

Unwind the mains lead from the cable holder on the rear of the

device. After using the device, please wind up the lead again.

CAUTION:

Do not move the device, as otherwise this might cause

the water to leak out and damage the ﬂ oor, carpet or

device.

Never use the air-conditioner without protective ﬁ lters.
