GRAPHITE 59G347 [13/88] Operation settings

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

The mains voltage must match the voltage on the rating plate of the sander.

Impulse (short) use: Press the switch button (2) and hold it.

Continuous operation: Press the switch button (2) and secure it in the position by pressing the switch lock

button (g. D)

Switching o Press and release pressure on switch button (2).

ROTATIONAL SPEED CONTROL KNOB WHEEL

Orbital sander works at various rotational speeds. Rotational speed is controlled using the rotational speed

control knob (wheel) (6). Control of rotational speed makes it possible to select rotational speed of the

power tool appropriate for processed material. Speed control range is 1-5 plus MAX.

The higher the number seen on the circumvent of the rotational speed control knob (wheel) (6) (g. E) the

higher rotational speed of the sander.

Proper selection of rotational speed is done when the orbital sander is running, without load, when the

switch lock button is pressed. Rotational speed selected when the sander is running under load can be

lower.

ORBITAL SANDER OPERATION

Ɣ Whole area of backing pad must rest on the processed surface.

Ɣ Turn the sander on and apply moderate pressure; move it on the processed material in circular

movements, in transverse or lengthwise direction.

Ɣ For coarse processing use sanding paper with coarse grain, for ﬁnishing processing use ﬁne-grained

paper. It is best to match the type of sanding paper by trials and errors.

Ɣ When ﬁnishing polishing, reduce pressure, lift the sander above the processed surface and only after

that switch the tool oﬀ.

OPERATION AND MAINTENANCE

Unplug the power cord from the mains socket before commencing any activities related to

installation, adjustment, repair or maintenance.

MAINTENANCE AND STORAGE

Ɣ It is recommended to clean the sander immediately after each use.

Ɣ Do not clean the device with water or other liquids.

Ɣ The device should be cleaned with a dry piece of cloth or with compressed air at low pressure. Do not use

any cleaning agents or solvents, as they may damage the parts made of plastic.

Ɣ Clean ventilation slots in the motor housing on regular basis to prevent overheating of the device.

Ɣ In case of excessive commutator sparking have the technical condition of carbon brushes of the motor

checked.

Ɣ The device must always be stored in a dry place out of reach of children.

REPLACEMENT / CHANGE OF SANDER BACKING PAD

If the sander backing pad must be replaced with another backing pad or when the backing pad is faulty,

please proceed as follows:

Ɣ Remove screws securing the backing pad (5) (gure G).

Ɣ Remove and replace the backing pad.

Ɣ Tighten the screws.

REPLACEMENT OF CARBON BRUSHES

Replace immediately used up (shorter than 5 mm), burnt or cracked motor carbon brushes. Always

replace both brushes at a time.

Entrust replacement of carbon brushes only to a qualied person. Only original parts should be used.
