GRAPHITE 56H800 [12/44] Technical parameters

TABLE OF RECOMMENDED ELECTRODES AND RECOMMENDED WELDING CURRENT DEPENDING ON

THICKNESS OF THE WELDED MATERIAL

mm Ø mm AMP

1,0 1,6 30 - 50

2,0 - 3,5 2,0 50 - 75

2,5 - 3,0 2,5 75 - 105

3,0 - 4,0 3,2 105 - 140

tecHnical parameterS

TECHNICAL PARAMETER UNIT 56H800 56H802 56H804

Supply voltage V AC 230 230/400 230/400

Current frequency Hz 50/60 50/60 50/60

Open-circuit voltage V 48 48 48

Maximum power consumption kW 6,2 7,0 10,0

Amperage A 55 - 160 60 - 180 80 - 250

Overload % 10 10 10

Protection class IP 21 21 21

Electrode diameter mm 2.0 - 4.0 2.0 - 4.0 2.0 - 5.0

Weight kg 16,5 17,0 20,5

Dimensions mm 480/300/375 480/300/375 480/300/375

Wastes produced with electrical machines cannot be processed like ordinary household wastes.

Recycle only where appropriate plants are available. Consult local authorities or the seller to obtain

instructions on gathering and disposing wastes.
