Hotpoint-Ariston C 3 VN1 R/HA [3/20] H hotpoint
![Hotpoint-Ariston C 3 VN1 R/HA [3/20] H hotpoint](/views2/1038329/page3/bg3.png)
Содержание
- Ariston 1
- Contents 1
- Cooker and oven 1
- Hotpoint 1
- Operating instructions 1
- Electrical connections 2
- Installation 2
- Positioning and levelling 2
- Ariston 3
- H hotpoint 3
- 1 1 j о s3 so o os oa 4
- Control panel 4
- Description of the appliance 4
- Overall view 4
- Ariston 5
- H hotpoint 5
- Start up and use 5
- Starting the oven 5
- Cooking modes 6
- Practical cooking advice 6
- Ariston 7
- H hotpoint 7
- Oven cooking advice table 7
- Cooking zones 8
- Switching the cooking zones on and off 8
- Using the glass ceramic hob 8
- Ariston 9
- Disposal 9
- General safety 9
- H hotpoint 9
- Precautions and tips 9
- Respecting and conserving the environment 9
- Assistance 10
- Care and maintenance 10
- Cleaning the glass ceramic hob 10
- Cleaning the oven 10
- Replacing the oven light bulb 10
- Switching the appliance off 10
- Ariston 11
- Кухонная плита с духовым шкафом 11
- Н hotpoint 11
- Руководство по эксплуатации 11
- Содержание 11
- Ri sì j 12
- Расположение и нивелировка 12
- Установка 12
- Электрическое подсоединение 12
- Ariston 13
- Я hotpoint 13
- Общий вид 14
- Описание изделия 14
- Панель управления 14
- Ariston 15
- Включение духового шкафа 15
- Включение и эксплуатация ц hotpoint 15
- Практические советы по приготовлению 16
- Программы приготовления 16
- Ariston 17
- Il hotpoint 17
- Таблица приготовления в духовом шкафу 17
- Включение и выключение нагревательных зон 18
- Нагревательные зоны 18
- Стеклокерамическая варочная панель 18
- Ariston 19
- H hotpoint 19
- Общие требования к безопасности 19
- Предосторожности и рекомендации 19
- Утилизация 19
- Экономия электроэнергии и охрана окружающей среды 19
- Отключение электропитания 20
- Порядок замены лампочки в духовом 20
- Техническое обслуживание 20
- Техническое обслуживание и уход 20
- Чистка деталей из нержавеющей стали 20
- Чистка духового шкафа 20
- Чистка стеклокерамическои варочной панели 20
- Шкафу 20
Похожие устройства
- Zanussi ZOB 535712 X Инструкция по эксплуатации
- Samsung MLT-D104S Инструкция по эксплуатации
- Supra IS-5740 Инструкция по эксплуатации
- Ritmix RF-9300 Инструкция по эксплуатации
- Zanussi ZOB 442 X Инструкция по эксплуатации
- LG WD-10340ND Инструкция по эксплуатации
- Samsung UE-32 D6100SW Инструкция по эксплуатации
- Supra IS-6850 Инструкция по эксплуатации
- Panasonic TH-50PHW6 Инструкция по эксплуатации
- Samsung UE-32 D6530WS Инструкция по эксплуатации
- Supra IS-9700 Инструкция по эксплуатации
- Vitek VT-1340 Инструкция по эксплуатации
- Whirlpool AKP 263 JA Инструкция по эксплуатации
- Samsung UE-40 D6100SW Инструкция по эксплуатации
- Supra IS-9750 Инструкция по эксплуатации
- Novex NK-1702RS Инструкция по эксплуатации
- Samsung UE-40 D6510WS Инструкция по эксплуатации
- Supra MFC-34 Инструкция по эксплуатации
- Samsung DVD-P355KD Инструкция по эксплуатации
- LG LB 642122 B Инструкция по эксплуатации
H Hotpoint ARISTON 5 Fix the power supply cable in place by fastening the cable clamp screw 6 Close the terminal board cover by tightening the screws V Connecting the supply cable to the mains Install a standardised plug corresponding to the load indicated on the data plate located on the appliance The appliance must be directly connected to the mains using an omnipolar circuit breaker with a minimum contact opening of 3 mm installed between the appliance and the mains The circuit breaker must be suitable for the charge indicated and must comply with current electrical regulations the earthing wire must not be interrupted by the circuit breaker The supply cable must be positioned so that it does not come into contact with temperatures higher than 50 C at any point Before connecting the appliance to the power supply make sure that The appliance is earthed and the plug is compliant with the law The socket can withstand the maximum power of the appliance which is indicated by the data plate The voltage is in the range between the values indicated on the data plate The socket is compatible with the plug of the appliance If the socket is incompatible with the plug ask an authorised technician to replace it Do not use extension cords or multiple sockets TECHNICAL DATA Oven dimensions HxWxD Volume Useful measurements relating to the oven compartment Power supply voltage and frequency Ceramic hob Front Left Back Left Back Right Front Right Max ceramic hob consumption ENERGY LABEL C GB 34x38x44 cm It 57 width 42 cm depth 44 cm height 17 cm see data plate 1200 W 1700 W 1200 W 1700 W 5800 W Directive 2002 40 EC on the label of electric ovens Standard EN 50304 Declared energy consumption for Natural convection Class heating mode d Static EC Directives 73 23 EEC dated 19 02 73 Low Voltage and subsequent amendments 89 336 EEC dated 03 05 89 Electromagnetic Compatibility and subsequent amendments 93 68 EEC dated 22 07 93 and subsequent amendments 2002 96 EC Once the appliance has been installed the power supply cable and the electrical socket must be easily accessible The cable must not be bent or compressed The cable must be checked regularly and replaced by authorised technicians only The manufacturer declines any liability should these safety measures not be observed Only available in certain models 3
