![Clarion VZ509E [26/70] English](/views2/1003895/page26/bg1a.png)
24
VZ509E
English
Owner’s manual
Selecting PTY
1. Touch the [Options] key.
2. Touch the [On] key of the PTY item to enter
the PTY standby mode.
3. Touch the [PTY Select] key to display the
PTY Select screen.
• If no operation is made within 7 seconds,
the system will return to the Options screen.
4. Touch your desired PTY Preset key to select
the program type.
• The following table shows the factory
default settings stored for the Preset keys:
5. Touch the [Back] key to return to the previous
screen.
● Canceling PTY standby mode
1. Touch the [Options] key.
2. Touch the [Off] key of the PTY item.
“PTY” goes off, and the PTY standby mode is
canceled.
● Canceling PTY interrupt broadcast
1. Touch the [Back] key during receiving the
PTY interrupt broadcast. The PTY interrupt is
canceled, and the system returns to PTY
standby mode.
• You can also cancel the PTY interrupt
broadcast by keeping pressing the [SRC]
button for more than 1 second.
● Changing the PTY language
1. Touch the [Options] key.
2. Touch the [PTY Language] key to display the
PTY Language screen.
3. Touch the desired Language key you wish to
set.
4. Touch the [Back] key to return to the previous
screen.
PTY seek
1. Touch the [Options] key.
2. Touch the [PTY Select] key to display the
PTY Select screen.
3. Touch your desired PTY Preset key to select
the program type.
• If no operation is made within 7 seconds,
the system will return to the Options screen.
• You can also select a program type from the
Items screen.
4. Touch a Seek key.
If you touch the [{ (P-seek)] key, the system
seeks a PTY broadcast moving up the
frequencies.
If you touch the [} (P-seek)] key, it seeks
moving down the frequencies.
• If no station with the selected PTY
broadcast can be received, the unit returns
to the previous mode.
PTY preset memory
1. Touch the [Options] key.
2. Touch the [PTY Select] key.
3. Touch the [Item] key to display the Items
screen.
• If no operation is made within 7 seconds,
the system will return to the Options screen.
4. Touch the desired PTY Item key to select the
program type you wish to store.
• You can scroll the list by touching [{] or [}]
key.
5. Touch the [Back] key to display the PTY
Select screen.
6. Touch and hold the desired PTY Preset key
you wish to store the currently selected
program type for more than 2 seconds.
• The 29 types of PTY listed below can be
selected.
Preset
number
PTY item
ENGLISH Contents
1NewsNews
2 Info Information
3 Pop M Pop music
4 Sport Sport
5 Classics Classics
6 Easy M Easy listening
music
PTY item
ENGLISH Contents
News News
Affairs Current Affairs
Info Information
Sport Sport
Educate Education
Drama Drama
Culture Culture
Science Science
Varied Varied
