27
VZ509E
English
Owner’s manual
Setting up the disc menu language
• The factory default setting is “English”.
Setting up the audio language
• The factory default setting is “English”.
Setting up the subtitle language
• The factory default setting is “English”.
Setting up the password for setting
up of the parental level
• The factory default setting is “0000”.
Note:
• When a disc with view restrictions is inserted, you
will be prompted to input a password. The disc will
not be viewable until the correct password is
entered.
Setting up the country code
Set up the country number for setting up of the
parental level.
• The factory default setting is “7166” (U.K.).
Country code list:
4-1. Touch the []] key of the Menu Language
item.
4-2. Touch the desired Language key you wish
to set.
4-3. Touch the [Back] key.
4-1. Touch the []] key of the Audio Language
item.
4-2. Touch the desired Language key you wish
to set.
4-3. Touch the [Back] key.
4-1. Touch the []] key of the Subtitle Language
item.
4-2. Touch the desired Language key you wish
to set.
• To turn off the subtitle, select the [Off] key.
4-3. Touch the [Back] key.
4-1. Touch the []] key of the Password item.
4-2. Touch the ten-key (0 to 9) to input a 4-digit
password.
• Input the old password, and touch the
[ENT] key.
Input “4356” to reset password.
• Input a new password, and touch the
[ENT] key.
• Input the same new password again, and
touch the [ENT] key.
4-1. Touch the []] key of the Country Code item.
4-2. Touch the ten-key (0 to 9) to input a 4-digit
country code (see the following table).
4-3. Touch the [ENT] key.
Country Input code
ALBANIA 6576
ANDORRA 6568
AUSTRIA 6584
BAHRAIN 6672
BELGIUM 6669
BOSNIA AND
HERZEGOWINA
6665
BULGARIA 6671
CROATIA (local name:
Hrvatska)
7282
CYPRUS 6789
CZECH REPUBLIC 6790
DENMARK 6875
EGYPT 6971
FINLAND 7073
FRANCE 7082
(FRANCE,METROPOLITAN) 7088
GERMANY 6869
GREECE 7182
HUNGARY 7285
ICELAND 7383
IRAN (ISLAMIC REPUBLIC
OF)
7382
IRAQ 7381
IRELAND 7369
ISRAEL 7376
ITALY 7384
