![Trotec Speedy 300 [7/60] Mechanics](/views2/1404700/page7/bg7.png)
8011 Trotec Speedy 300
GENERAL
28/07/2015 Trotec Laser GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 7 / 60
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, mailto: techsupport@troteclaser.com
1.4 Technical Data / Device Specification
Mechanics
Working area
29“ x 17“ / 726 mm x 432 mm
Max. height of work piece
7,8 inch / 200 mm with 1,5 inch lens
7,8 inch / 200 mm with 2,0 inch lens
7,3 inch / 187 mm with 2,5 inch lens
5,9 inch / 149 mm with 4,0 inch lens
Max. engraving speed
140 inch/sec / 355 cm/sec.
Cutting speed
depending on material, thickness, laser power
Motor
Brushless DC servo
Encoder
Increment
Work piece table
Solid metal (Ferro-magnetic)
Max. load of work piece table
44 lbs / 20 kg
Lenses
1.5”, 2.0”, 2.5” or 4.0“
Features
Standard:
Electro-optic autofocus, Laser pointer (655nm, < 0,99mWcw), Coaxial air assist (without pump), Ferro-
magnetic working table, 1,5” lens, USB connection, JobControl Expert software
Optional:
Honeycomb cutting table, Rotary attachment, Harsh environment protection kit, Laser power upgrade,
Air assist including compressor, Temperature sensor, Vacuum table, Data import MAC, Double-head
feature, MCO (Multi Color Option; see separate data sheet)
Control System
Laser power
Adjustable from 0 - 100% (typically 10-100%)
Interface Hardware
RS-232-C: Data Rate 19.200 -115.200 Baud
USB: Data Rate 460.800 Baud
Interface Software
JobControl, HPGL
Laser Equipment
Laser tube
Sealed off CO
2
Laser, maintenance free
Laser power: 12W - 120W
Wavelength
10,6µm
Cooling System
Air cooling unit
12W – 120W units air-cooled
Water cooling unit
Additionally 60W, 105W and 120W units water-cooled
Electricity, Power, Fuse
12W to 80W units
Single phase 230V / 50Hz or 115V / 60 Hz
85W to 120W units
Single phase 230V / 50 - 60Hz
Power consumption
2900W for 120W unit
Recommended fuse
10A (230V/115V) for 12W - 45W unit
10A (230V), 20A (115V) for 60W-water-cooled unit
16A (230V), 20A (115V) for 60W - 80W unit
16A (230V) for 85W - 120W unit
