8011 Trotec Speedy 300
GENERAL
28/07/2015 Trotec Laser GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 8 / 60
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, mailto: techsupport@troteclaser.com
Dimensions
Width/depth/height (approx.)
1090mm x 890mm x 590mm / 43” x 35” x 22”
Weight (approx.)
297 lbs / 135 kg for 25W version
Ambient Conditions
Ambient temperature
+15°C to +25°C / 59°F to 77°F
Humidity
40% to max. 70%, not condensing
Laser Safety
Laser class
CDRH Laser Safety
Laser Class 2(M)
CE compliant, FDA approved
Interlock
Double Interlock safety system
