Airwell K 45 OG [10/16] Dimensions
![Airwell K 45 OG [10/16] Dimensions](/views2/1408171/page10/bga.png)
Page 10
Dimensions
2-pipe units
DESCRIPTION
1 False ceiling 7 Draining of condensates (Ø1/2")
2 T-shaped rod (false ceiling) 8 Coupling of water inlet (G1")
3 Heat exchanger 9 Coupling of water outlet (G1")
4 Fan 10 Port to distribute air through a duct into a neighbouring room (pre-punched)
5 Suction grille 11 Port to suction fresh air (pre-punched)
6 Electric box (removable)
