Airwell K 45 OG [8/16] Field of operation
![Airwell K 45 OG [8/16] Field of operation](/views2/1408171/page8/bg8.png)
Page 8
Field of Operation
Using chilled water
Using hot water (electric heating forbidden)
Characteristics
Indoor temperature °C
Thi 13
Tsi
17
Cooling water °C Twe 3
Indoor temperature °C
Thi 22
Tsi
32
Cooling water °C Tse 18
Maximum indoor temperature °C
Thi 22
Tsi
32
Maximum entering water temperature °C Twe 60
MINIMUM
TEMPERATURE
MAXIMUM
TEMPERATURE
Models 30 45
Contents l 2.7 4
Max. pressure of operation bar 15 15
Testing pressure
bar 24 24
Couplings
inch
1" gas male 1" gas male
mm
26-34 male 26-34 male
Thi : Indoor wet bulb.
Tsi : Indoor dry bulb.
Tse : Outdoor dry bulb.
Twe :
Entering water temperature.
